Tata Tiscon
Tata Tiscon :
Features of TATA TISCON SD Rebars :
Ductility and UTS (Ultimate Tensile Strength) greater than the standard specification, ensuring highest level of safety.
Easy Weldability owing to low carbonequivalent
Minimum impurities of Sulpur & Phosphorus
Higher bendability due to specialized inherent microstructure with soft inner core, giving it tremendous capacity to absorb energy beyond yield limits, which helps the structure stay safe and strong in times of natural calamities as well.
Higher Bond Tremgth : TISCON 500 Bars have specialised rib patterns, which is designed by automated top notch machines. Uniform rib pattern on the Bar helps in quality bonding with reinforced concrete cement.
Fire, Fatigue, Seismic Resistance
Cost Friendly : Use of TISCON 500 ensures savings in usage of steel by up to 17%. It comes with lower and uniform sectional weight resulting in further saving of 3-4% .
Product Range :
TISCON 500 is available in following size ranges.
Size ( mm ) : 6, 8, 10, 12, 16, 20, 22, 25, 28, 32, 36 and 40mm
Section (mm) | Nominal weight (kg/metre) | Nominal Lengths (Metre/MT approx.) |
---|---|---|
6 | 0.22 | 4545 |
8 | 0.395 | 2531 |
10 | 0.617 | 1620 |
12 | 0.888 | 1126 |
16 | 1.58 | 633 |
20 | 2.47 | 405 |
25 | 3.85 | 260 |
28 | 4.83 | 207 |
32 | 6.31 | 159 |
36 | 7.99 | 125 |
40 | 9.85 | 102 |
Chemical Properties
Chemical Properties | Unit | IS:1786, Fe 500 | IS:1786, Fe 500D | TISCON 500D* |
---|---|---|---|---|
Carbon | % | 0.300 max | 0.250 max | 0.250 max |
Carbon equivalent ( C+ Mn/6) | % | 0.420 max | 0.420 max | 0.400 max |
Sulphur | % | 0.055 max | 0.040 max | 0.035 max |
Phosphorus | % | 0.055 max | 0.040 max | 0.035 max |
S and P | % | 0.105 max | 0.075 max | 0.070 max |
Mechanical Properties
Chemical Properties | Unit | IS:1786, Fe 500 | IS:1786, Fe 500D | TISCON 500D* |
---|---|---|---|---|
Yield Stress (YS) | N/mm2 | 500 min | 500 min | 540 min |
Ultifmate Tensile Strength (UTS) | N/mm2 | 545 min | 565 min | 600 min |
UTS/YS | Ratio | 1.08 min | 1.10 min | 1.12 min |
Elongation | % | 12 min | 16 min | 1.12 min |
